☑ Features
- One-way automatic shut-off valve in the socket.
- Wide variety provides best choice accordingly to application.
- Hardened important parts are extremely wear resistant and durable.
- Tested 100,000 times, coupler connection is accurate and reliable.
☑ Application
Pneumatic tools、Air piping、Air pressure equipment
☑ Specification
Part No. | 20 SP | 30 SP | 40 SP | 45 SP | 50 SP |
|---|---|---|---|---|---|
Hose Size | 5 x 8 mm | 6.5 x 10 mm | 8 x 12 mm | 10 x 14 mm | 11 x 16 mm |
Thread | PT | ||||
Working Pressure | 218 PSI (15 Bar / 1.5 MPa) | ||||
Maximum Pressure | 290 PSI (20 Bar / 2 MPa) | ||||
Temperature Range | -20 ℃ ~ +80 ℃ | ||||
