☑ Features
- Improved operation.
- Chrome plated steel body for anti-corrosion.
- One-touch series couplers could be widely applied for male and female thread connections, hose connectors and manifolds.
☑ Application
Pneumatic tools、Air piping、Air pressure equipment
☑ Specification
Part No. | 20 SPT | 30 SPT | 40 SPT | 45 SPT | 50 SPT |
|---|---|---|---|---|---|
Hose Size | 5 x 8 mm | 6.5 x 10 mm | 8 x 12 mm | 10 x 14 mm | 11 x 16 mm |
Thread | PT | ||||
Working Pressure | 218 PSI (15 Bar / 1.5 MPa) | ||||
Maximum Pressure | 290 PSI (20 Bar / 2 MPa) | ||||
Temperature Range | -20 ℃ ~ +80 ℃ | ||||
